Drawn-Seamless EMI/RFI Shields

MS Part #

Configuration

Length

Width

Height

Ventilation

Raw Material

Packaging

COO

MS Part #	Configuration	Length	Width	Height	Ventilation	Raw Material	Packaging	COO
Get MS220-20F 22 x 17.7 x 3mm Two-piece Drawn-Seamless RF Shield / EMI Shield FRAME	2-piece EMI/RFI Shield FRAME	22 mm	17.7 mm	3 mm	Non-Vented	Tin-Steel (CRS)	Tray	IL (Israel)
Get MS220-20F-NS 22 x 17.7 x 3mm Two-piece Drawn-Seamless RF Shield / EMI Shield FRAME	2-piece EMI/RFI Shield FRAME	22 mm	17.7 mm	3 mm	Non-Vented	Nickel-Silver	Tray	IL (Israel)
Get MS220-20S 22 x 17.7 x 3mm One-piece Drawn-Seamless RF Shield / EMI Shield	1-piece EMI/RFI Shield	22 mm	17.7 mm	3 mm	Non-Vented	Tin-Steel (CRS)	Tray	IL (Israel)
Get MS220-20S-NS 22 x 17.7 x 3mm One-piece Drawn-Seamless RF Shield / EMI Shield	1-piece EMI/RFI Shield	22 mm	17.7 mm	3 mm	Non-Vented	Nickel-Silver	Tray	IL (Israel)
Get MS220-30C 22.6 x 11.9 x 2.8mm Two-piece Drawn-Seamless RF Shield / EMI Shield COVER	2-piece EMI/RFI Shield COVER	22.6 mm	11.9 mm	2.8 mm	Non-Vented	Tin-Steel (CRS)	Tray	IL (Israel)
Get MS220-30C-NS 22.6 x 11.9 x 2.8mm Two-piece Drawn-Seamless RF Shield / EMI Shield COVER	2-piece EMI/RFI Shield COVER	22.6 mm	11.9 mm	2.8 mm	Non-Vented	Nickel-Silver	Tray	IL (Israel)
Get MS220-30CP 22.6 x 11.9 x 2.8mm Two-piece Drawn-Seamless RF Shield / EMI Shield COVER Perforated	2-piece EMI/RFI Shield COVER	22.6 mm	11.9 mm	2.8 mm	Vented	Tin-Steel (CRS)	Tray	IL (Israel)
Get MS220-30CP-NS 22.6 x 11.9 x 2.8mm Two-piece Drawn-Seamless RF Shield / EMI Shield COVER Perforated	2-piece EMI/RFI Shield COVER	22.6 mm	11.9 mm	2.8 mm	Vented	Nickel-Silver	Tray	IL (Israel)
Get MS220-30F 22 x 11.3 x 2.8mm Two-piece Drawn-Seamless RF Shield / EMI Shield FRAME	2-piece EMI/RFI Shield FRAME	22 mm	11.3 mm	2.8 mm	Non-Vented	Tin-Steel (CRS)	Tray	IL (Israel)
Get MS220-30F-NS 22 x 11.3 x 2.8mm Two-piece Drawn-Seamless RF Shield / EMI Shield FRAME	2-piece EMI/RFI Shield FRAME	22 mm	11.3 mm	2.8 mm	Non-Vented	Nickel-Silver	Tray	IL (Israel)
Get MS220-30S 22 x 11.3 x 2.8mm One-piece Drawn-Seamless RF Shield / EMI Shield	1-piece EMI/RFI Shield	22 mm	11.3 mm	2.8 mm	Non-Vented	Tin-Steel (CRS)	Tray	IL (Israel)
Get MS220-30S-NS 22 x 11.3 x 2.8mm One-piece Drawn-Seamless RF Shield / EMI Shield	1-piece EMI/RFI Shield	22 mm	11.3 mm	2.8 mm	Non-Vented	Nickel-Silver	Tray	IL (Israel)
